System Setup 2 Menu

Field Name Range
Local Mode Enable /
Disable
Check box.
Rptr
Enable /
Independent
Disable
Channel Change Check box.
System Mode
Enable /
Tones – Trailing Disable
Check box.
System Mode
Enable /
Tones – Lead
Disable
Check box.
Busy Lockout
Enable /
MBX2
Disable
Compatibility Check box.
Busy Lockout 0 - 127
ID
Busy Lockout
0 – 180
Master Bit Clr
minutes
Time
Local Mode Enable /
Tones – Trailing
Disable
Check box.
Local Mode Enable /
Tones – Lead Disable
Check box.
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
Enables / Disables Local DVR
Mode.
Enables / Disables the DVR
channel strapping to the MSU Talk
Groups.
Enables or Disables the Trailing
Tones sent by the DVR to the Local
PSUs to indicate successful
transmission to the trunked system
The tones are sent at the end of
LPSU transmission.
Enables or Disables the Lead Go
Ahead Tones sent by the DVR to
the Local PSUs to indicate
successful / unsuccessful
transmission to the trunked system.
The tones are sent at the beginning
of LPSU transmission. The LPSU
user needs to do 'double PTT' in
order to be able to hear the Lead
tones.
When Enabled, the DVR changes
its voting algorithm so it is
compatible with older style
Mobexcom II VRs.
If MBX Compatibility is Enabled,
each DVR/VR needs to be
programmed with a different ID.
Larger fleets may have duplicate
IDs programmed, preferably in
different operation areas.
If enabled (set to >0), the last DVR
that was voted a Primary will have
a priority in the next voting for the
duration of the timer. The timer is
reset every time a DVR is voted a
Primary.
Enables or Disables the Trailing
Tones sent by the DVR to the Local
PSUs to indicate successful
transmission to the trunking
system. The tones are sent at the
end of LPSU transmission.
Enables or Disables the Lead Go
Ahead Tones sent by the DVR to
the Local PSUs to indicate
successful / unsuccessful
transmission to the trunked system.
The tones are sent at the beginning
of LPSU transmission. The LPSU
user needs to do 'double PTT' in
order to be able to hear the Lead
tones.
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
6881013Y39
Notes
Affects Analog DVR Mode when
used with Trunked MSU mode
only. The tones are heard by all
LPSU users that are on the
selected DVR channel since they
are sent over the air (not
generated in the LPSU).
Affects Analog DVR Mode when
used with Trunked MSU mode
only. The tones are heard by all
LPSU users that are on the
selected DVR channel since they
are sent over the air (not
generated in the LPSU).
Applicable to Analog mode only.
Applicable to Analog mode only.
Applicable to Analog mode only.
Default setting is 0 i.e. Disabled
and all DVRS units have the
same chance of becoming a
Primary during every voting.
Affects Analog DVR Mode when
used with Trunked MSU mode
only. The tones are heard by all
LPSU users that are on the
selected DVR channel since they
are sent over the air (not
generated in the LPSU).
Affects Analog DVR Mode when
used with Trunked MSU mode
only. The tones are heard by all
LPSU users that are on the
selected DVR channel since they
are sent over the air (not
generated in the LPSU).
TM
2500 (M5)
Page 33 of 79
