Appendix 2 – DVR Status Display
O5 / O3 DISPLAY ICON
/ MESSAGE
Steady V R
Steady
Steady
Steady
Flashing V R
Flashing
V R
Steady
V R
Flashing
Steady
Steady
Steady
VR SERVICE
VR ERROR
VR IN RESET
VR DISABLED
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
DVRS STATUS DESCRIPTION
DVR is in a Primary State
Primary DVR Receiving
Primary DVR Transmitting
Primary DVR Receiving and Transmitting
DVR is in a Secondary State
Secondary DVR Receiving
DVR is in a Permanent Primary State
DVR is in a Permanent Primary 'On Standby' State (there is
another Permanent Primary already present in the area)
Permanent Primary DVR Receiving
Permanent Primary DVR Transmitting
Permanent Primary DVR Receiving and Transmitting
DVR is in Service Mode (during re-flashing of the firmware).
DVR Detected Error. Display toggles between VR ERROR
and the actual error code / number.
DVR is being reset
DVR Disabled on Selected MSU TG / Mode
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
6881013Y39
