Control Head Menu - Futurecom Mobexcom P25 Installation & Programming Manual

Field Name Range
DTMF Remote Up to 5
Control Code digits.
Power Up Mode
Fixed
Last
Programmed
Fixed Mode
System
Local
OFF
Channel Disable –
max # of
programmed
DVR
channels
No Activity Timer
Disable –
- Repeater
120 min
System Channel
200 – 2550
Acquisition Time
ms

Control Head Menu

The Control Head menu enables the selection of Language – English or French.
IMPORTANT
The MSU and DVR need to be programmed for the same Language support.
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
Upon receiving a matching DTMF
sequence from a PSU, the DVR
switches from OFF or Local to
System Mode. The DVR and PSU
must be programmed with the
same DTMF sequence.
Specifies the DVR Mode upon
Power Up.
Specifies the DVR Mode when
Fixed Power up option is selected.
Typical recommended setting is
OFF.
Specifies the Default DVR Power
up Channel. If set to Disable, the
DVR reverts to the last used
channel upon Power up.
If the DVR is not active (does not
receive any local PSU calls) for the
programmed period of time, it will
automatically switch from System
or Local to OFF Mode. The DVR
sends warning tones to alert the
Local PSU users every minute
during the last 5 minutes prior to
switching OFF.
Determines the DVR wait time for
receiving system grant before the
DVR decides what tones (ACK or
NACK) must be sent to the Local
PSUs.
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
6881013Y39
Notes
Affects Analog Mode only.
The PSU must be programmed
with * as the last DTMF sign, for
example 1234*.
Outbound calls, received by the
MSU and repeated by the DVR
will not reset the timer.
TM
2500 (M5)
Page 34 of 79
