Futurecom Mobexcom P25 Installation & Programming Manual page 72

Field Name Range
Ack to Portable Enable /
after LCAS Disable
Check box.
ANI 5 Tone Type
EEA
CCIR
EIA
Emergency
Cancel
Signaling Type Disable
ANI 5-Tones
DTMF
Emergency OFF-600sec
Cancel
Timeout
Emergency
number
Cancel
ANI Code
FG Emergency
Local
Destination
System
Both
Put MSU in
Yes / No
Emergency on
Analog DVR Ch.
Enable /
TG1 Translation
Disable
Disabled
check box
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
When Enabled, the DVR sends
Emergency ACK tone and
signaling to the Analog PSU only
after the Analog PSU has
unkeyed.
Determines the ANI 5-Tone Type.
Must match the Analog PSU
programming.
Typically set to Disable.
If enabled, the DVR will clear the
emergency upon detection of the
programmed Emergency Cancel
Code.
If programmed, the DVR will
automatically clear the
emergency upon expiration of the
programmed timer.
This field specifies the
Emergency Cancel ANI /DTMF
Code sequence. Must match the
Analog PSU programming.
Determines the routing of
Emergency message received by
the DVR from a Local PSU on a
FG enabled DVR channel.
If set to 'Yes', the MSU is put in
Emergency state upon decoding
MDC emergency from (and
sending an ACK to) the Local
PSU. The MSU then behaves
according to its programmed
Emergency settings. If set to 'No',
the emergency is processed via
the DVR & MSU without placing
the MSU in emergency.
Default setting is unchecked
(TG1 translation is enabled). In
this case when a
emergency is received
default TG1), the DVR translates
the TG ID to match the currently
selected MSU TG ID. This way
the emergency is announced on
the selected MSU TG, not on TG
1, which may not even exist in
the specific trunking system.
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
Notes
Affects Analog Mode only.
Affects Analog Mode only.
Affects Analog Mode only.
Affects all modes.
Affects Analog Mode only.
Applicable only if the Emergency
Cancel Signaling Type Field is
Enabled.
The PSU must be programmed
with * as the last DTMF sign, for
example 1234*.
Applicable to DVR channels which
have FG signaling enabled.
Affects Analog Mode Only.
Must be enabled if Emergency Call
and Emergency Revert are
required.
PSU
(on
Applicable to Fireground Analog,
Mixed and TPS type DVR
channels.
TM
2500 (M5)
6881013Y39
Page 36 of 79
