AVRA

The Automated VR Activation (AVRA) option enables automated DVR ON/OFF control
triggered by an external switch – portable charger, door switch etc.
If this option is desired, the external switch (provided by others) needs to be wired to one
of the following:
A dedicated VIP Input on the O5 Control Head or DEK.
o The 'Automatic VR Activation' and 'AVRA Uses VIP on CH' selection
boxes in the DVRS Hardware Setup menu must be checked.
o The corresponding VIP I/P must be enabled in the XTL
5000 – refer to the Programming Guide provided by Motorola for detailed
instructions.
For detailed instructions on VIP wiring, please refer to the XTL
Installation Manuals available from Motorola.
'Switch 1 Input' on the DB15 of the DVR Auxiliary Cable (PN 7W083X06).
o The 'Automatic VR Activation' selection box in the DVRS Hardware Setup
Menu must be checked.
o The 'AVRA Uses VIP on CH' selection box in the DVRS Hardware Setup
menu must be left blank (unchecked).
o The XTL
to the enabling of this option.

Status Lights

The Status Lights Option provides status identification capabilities. The Relay outputs in
the DVRS can be programmed to provide several status indications – 'Master Light',
'LOC Mode Light', 'SYS Mode Light' or 'DVR ON Light' .
The DVR then provides control input to an external switch which in turn toggles an
external light.
The external switch and light are not included with the DVR.
The Light Switch Relay Coil "+" must be wired to +12V DC and the "-" to the
corresponding Relay Output on the DB15 connector of the DVR Auxiliary cable PN
7W083X06 (500mA Max).

External Alarm

In applications where the DVR is installed in a fixed 19" rack, the external alarms option
can be enabled and the corresponding relay output wired up to an external logic system
for monitoring and reporting of 'low power' or 'overt temperature' combined alarms.
Duplexer Bypass Switch
If this option is installed, the DVR duplexer can be switched out whenever a simplex
DVR channel is selected. This feature is only applicable to Cross-Band DVRS
Configurations and provides frequency plan flexibility. The Duplexer Bypass Switch is
wired to Relay 1 (pin 6) of the Auxiliary cable connector and the DVR needs to be
programmed accordingly.
