Analog DVR Mode - Operation and Programming Overview

The Analog Mode supported Features are listed in

DVR Channel Setup for Analog Mode

To enable Analog DVR operation on a specific DVR channel the Channel Type (in the
Repeater Channel Setup Menu) must be set to Analog.
The DVR Tx / Rx Frequencies as well as the Tx / Rx PL or DPL must be programmed to
match the corresponding PSU settings.
NOTE:
Mixed DVR mode allows Analog DVR operation by switching between Digital and
Analog modes as described in the Mixed DVRS Mode section. The use of Mixed mode
for Analog DVRS communications is not recommended since it requires special User
Training. Mixed DVR mode should only be used when both analog and digital PSUs are
required to operate on the same DVR channel.

Group Calls

An Analog Local PSU in DVRS mode can communicate with other Analog Local PSUs
via an active Primary DVRS if all units are using the same radio channel (full duplex
only) and using matching PL / DPLs.
Inbound PSU calls will be repeated on the MSU side over the currently selected MSU
TG / Channel.
Outbound calls received by the MSU are repeated to the Local Analog PSUs.

Emergency in Analog Mode

The Emergency operation in Analog Mode is based on the type of signaling as selected
in the Emergency Mode Setup Menu. The recommended Analog Mode signaling type is
MDC1200. Note that in addition to the DVR programming, MDC1200 signaling must also
be enabled in the Local PSU personality.
The following MDC1200 Emergency scenarios can be supported by DVRS if
programmed:
MSU Emerg. Type (P25
or TII Trunking)
Emergency Alarm
Emergency Call
Emergency Call & Alarm Emergency Alarm
If the DVRS is in the OFF mode when the Local PSU sends the Emergency, the DVRS
will switch to the System Mode and process the Emergency after the Emergency
Attempts Counter expires and the Emergency is not processed by another Primary DVR.
If MDC 1200 signaling is used, the Local PSU Emergency Alarm MDC ID will be passed
through to the System provided the MDC ID is enabled (valid) on the System side.
NOTE:
MDC PTT ID pass-through is not supported by DVRS.
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Local PSU Emerg.
(MDC1200)
Emergency Alarm
-
OR
Emergency Call & Alarm
TM
5000 (O3 or O5) or XTL
Appendix 8, 9, 10 & 11.
Notes
To support Emergency Call
from PSU, the DVR must be
programmed to put MSU in
Emergency – see Emergency
Mode setup menu.
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
Page 51 of 79
