Field Name Range
Battery Drop OFF – 9
OFF Volts
Threshold
MSU RF Enable /
Bypass Disable
Switch check box
External
Enable /
Master Light
Disable
check box
Relay Use 'Not Used'
'MSU RF
Bypass SW'
'Duplexer
Bypass SW'
'Master
Light'
'LOC Mode
Light'
'SYS Mode
Light'
'DVR ON
light'
'External
Alarm'
AFC Enable
Cumulative
Disable
AFC Fast Enable
Disable

MSU Data

This 'read only' screen provides MSU data for information purposes only. The MSU data
indicates what MSU was used as the source of the csv import / export.
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
In most installations the DVR is
programmed to be in the OFF mode
upon power up. If not, the
Drop off Threshold' field may be
enabled to prevent the DVR from
transmitting when the voltage drops
below the programmed threshold during
engine start up.
This field must be enabled on all in-
band DVR models equipped with an RF
Switch.
Relay 1 must be selected in the 'Relay
Use' field due to the Auxiliary Cable
wiring (see Figure 25).
This field needs to be enabled on DVR
models using an external light which is
lit when a DVR is a Primary or
Permanent Primary.
Relay 2 must be selected in the 'Relay
Use' field due to the Auxiliary Cable
wiring (see Figure 25).
Relay 1 must be assigned to the RF
Switch OR the Duplexer Bypass Switch
if the corresponding option is installed.
Relay 2 must be assigned to the Master
Light if this option is installed.
The MSU RF Switch option is included
with all side-by-side and Transportable
in-band models.
Enables or Disables the Cumulative
Automated Frequency Control (AFC)
tuning.
Enables or Disables the Fast AFC
tuning.
TM
5000 (O3 or O5) or XTL
This option may be useful only
in installations where the DVR
'Battery is programmed to power up in
System or Local mode. Since
the recommended DVR Power
up mode is OFF, this option is
not needed in most
installations. Default setting is
OFF.
Applies to In-Band DVRS
Models Only. This option
enables the Switch connecting
the in-band filtering at the
output of the MSU.
This option requires external
switching logic and hardware
(provided by others).
Refer to Figure 25
Cable information.
All Lights, Alarm relays and
associated external logic are to
be provided by others.
Default setting is Enable. Set to
Disable during calibration.
Default setting is Enable. Set to
Disable during calibration.
TM
2500 (M5)
8M083X01 Rev. 16
6881013Y39
Notes
