Futurecom Mobexcom P25 Installation & Programming Manual page 58

Field Name Options
/ Units
Man Mod Ch Enabled
Disabled
Tx Pwr
20-40
dBm
R-Tx Pwr
20-39
dBm
CCT 0-60 min
ON/OFF Trigger RSSI
Squelch
Sq&RSSI
RSSI Thresh -50 to
-127dBm
Busy Lc Th -65 to
-105 dBm
Rx NID (h) Hex #
Tx NID (h) Hex #
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
Enables / Disables the DVR mode
change from the VRS button on the
Control Head. If this field is set to
Disabled, the VRS button still
toggles between the default DVR
mode and OFF mode.
Specifies the selected Tx Output
Power at the DVR Antenna Port on
the DVR Tx frequency.
Specifies the selected Tx Output
Power at the DVR Antenna Port
when the DVR transmits on its Rx
frequency to other DVRs.
Refer to the Primary /Secondary
Operation Paragraph for more
details.
Continuous Carrier Timer –
specifies the maximum time a DVR
can be transmitting before its Tx
function is disabled. If the CCT is
set to 0 (OFF), the DVR operates in
continuous duty mode.
Analog Mode – any ON/OFF trigger
can be selected.
Digital Mode – RSSI only allowed.
Mixed Mode – RSSI only allowed.
Default Setting is -110dBm.
Threshold used during the dynamic
Busy Lockout Phase if Master /
Slave Enable BL for Voice Comm
is enabled (see Digital Mode
Settings menu).
Must match the P25 PSU Tx NID.
Serves as CAS validation in Digital
Mode (equivalent to Rx PL/DPL in
Analog Mode).
F7E Enables the DVR to receive
on any NID.
Must match the P25 PSU Rx NID.
Serves as CAS validation in Digital
Mode (equivalent to Tx PL/DPL in
Analog Mode).
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
6881013Y39
Notes
This field is automatically set to
Enabled when the VR Mode is set
to User.
The Duplexer Tx Insertion Losses
as entered in the Interface to
Mobile Setup screen are
compensated by the DVR PA
Output to produce the
programmed Tx Power at the
Antenna Port.
The Duplexer Rx Insertion Losses
as entered in the Interface to
Mobile Setup screen are
compensated by the DVR PA
Output to produce the
programmed Tx Power at the
Antenna Port.
Does not affect Telephone
Interconnect Calls. Phone calls
have a separate CTT programmed
in the Digital System Setup.
Squelch is invalid setting in Digital,
F. Analog or Mixed Mode DVR
Channels.
The Duplexer Rx Insertion Losses
as entered in the Interface to
Mobile Setup screen are taken
into account to produce the
programmed RSSI at the Antenna
Port.
Refer to the Primary /Secondary
Operation Paragraph for more
details.
Applies to Digital, Mixed and
F.Analog Mode.
Applies to Digital, Mixed and
F.Analog Mode.
TM
2500 (M5)
Page 22 of 79
