O5
Figure 3 700MHz In-Band DVRS Simplified Block Diagram
Figure 4 Typical In-Band DVRS Mounting Layout - 700 / 800 MHz
NOTE
The DVR and MSU always require two separate antennas.
NOTE
The In-Band filters connected to the MSU have typical insertion loss of 1.5dB.
April 2014
DVRS Installation & Programming Guide – PART I
Speaker
Remote Mount XTL5000
800MHz
Tx/Rx
Tx
Mobexcom P25 DVR
700MHz
Rx
8M083X01 Rev. 16
6881013Y39
RF SW
Notch
Filters
Duplexer
Page 8 of 30
