Futurecom Mobexcom P25 Installation & Programming Manual page 62

Field Name Range
VRch number
TG Mode
None
Local
System
User
Disabled
OFF
Manual Mode Chg Enabled
Disabled
Half Duplex Audio Yes / No
In Car Monitor Yes / No
VR Ch All Alwd Yes / No
Digital Vehicular Repeater Interfaced to XTL
April 2014
DVRS Installation & Programming Guide – PART II
Description
If Independent Channel Change
Disabled (i.e. DVR Ch Slaving is
enabled), this field determines which
DVR Channel will be automatically
selected upon selection of the
specified Mobile Radio Mode (TG or
Channel).
Enables or Disables Slaving of the
DVR Mode to the selected TG.
 this selection assumes no
'None'
specific DVR Mode is linked to the
TG. The DVR stays in the last mode
or the Mode associated with the DVR
Channel.
 This selection
'Local' / 'System'
forces the DVR Mode to change to
either Local or System respectively
upon selection of the TG.
 The Last DVR Mode that
'User'
was selected by the User is in effect
and the User can change it as
required.
 DVR is Disabled when
'Disabled'
this TG is selected.
 DVR is in OFF mode when
'OFF'
this TG is selected.
Enables or Disables the Mode
change (SYS / LOC) via the VRS
button when a specific TG is
selected.
Enables or Disables Half Duplex
Operation when a specific TG is
selected.
Enables or Disables the Audio
received from the Local PSU to be
heard in the MSU speaker.
This field specifies if the User can
select from any programmed DVR
channel or from a short list. If
Strapping is Enabled, the DVR will
steer to the programmed strapped
DVR channel, yet the User may still
be able to select a different channel if
more then one entries are enabled in
the 'VR Ch List'.
TM
5000 (O3 or O5) or XTL
8M083X01 Rev. 16
6881013Y39
Notes
is 'Slaving' is Enabled /
Disabled by the
Independent Channel
Change Field in the
System Setup 2
Applicable to both Analog
and Digital DVR Modes.
The 'Disabled' setting is
provided for test purposes.
Applicable to both Analog
and Digital DVR Modes.
Manual Mode change is
also selectable by DVR
Channel (see Repeater
Channel Setup Menu).
In Half Duplex Mode the
DVR's local audio repeat
function is disabled.
Applicable to System and
Local Mode.
Digital DVR channels are
only allowed on P25
Trunking or P25
Conventional Mobile Radio
Modes. If this field is set to
'Yes' and the MSU contains
Type II trunking or
Conventional Analog type
channels, the Tweaker will
mark those modes in red
and refuse to save to the
DVR EEPROM if one or
more of the DVR channels
are Digital. In such cases,
this field must be changed
to 'No' and only compatible
DVR channels must be
specified in the 'VR CH.
List' (see below) for each
MSU mode.
TM
2500 (M5)
Page 26 of 79
Menu.
