1.3.9

J-Trace for Cortex-M

J-Trace for Cortex-M is a JTAG/SWD emulator designed for Cor-
tex-M cores which includes trace (ETM) support. J-Trace for
Cortex-M can also be used as a J-Link and it also supports
ARM7/9 cores. Tracing on ARM7/9 targets is not supported.
1.3.9.1 Additional features
• Has all the J-Link functionality
• Supports tracing on Cortex-M targets
• Comes with built-in licenses for: Unlimited number of
breakpoints in flash (FlashBP), J-Link GDBServer, J-Link
RDI, J-Link RDDI and J-Flash (production programming
software).
1.3.9.2 Specifications
The following table gives an overview about the specifications (general, mechanical,
electrical) for J-Trace for Cortex-M. All values are valid for the latest hardware ver-
sion of J-Trace for Cortex-M.
Supported OS
Electromagnetic compatibility (EMC)
Operating temperature
Storage temperature
Relative humidity (non-condensing)
Size (without cables)
Weight (without cables)
USB interface
Target interface
Power supply
Target interface voltage (V
Target supply voltage
Target supply current
LOW level input voltage (V
HIGH level input voltage (V
Data input rise time (T
Data input fall time (T
Data output rise time (T
Data output fall time (T
Table 1.6: J-Trace for Cortex-M3 specifications
J-Link / J-Trace (UM08001)
General
Mechanical
JTAG/SWD Interface, Electrical
)
IF
)
IL
)
IH
JTAG/SWD Interface, Timing
)
rdi
)
fdi
)
rdo
)
fdo
For a complete list of all operating sys-
tems which are supported, please refer
to Supported OS on page 19.
EN 55022, EN 55024
+5°C ... +60°C
-20°C ... +65 °C
Max. 90% rH
123mm x 68mm x 30mm
120g
USB 2.0, Hi-Speed
JTAG/SWD 20-pin
(14-pin adapter available)
JTAG/SWD + Trace 19-pin
USB powered
Max. 50mA + Target Supply current.
1.2V ... 5V
4.5V ... 5V (if powered with 5V on USB)
Max. 300mA
Max. 40% of V
IF
Min. 60% of V
IF
Max. 20ns
Max. 20ns
Max. 10ns
Max. 10ns
