Permitted combinations are:
SWO output
6MHz, n = 12
4MHz, n = 18
...
2MHz, n = 36
...
Table 5.7: Permitted SWO speed combinations
Example 2
Target CPU running at 10 MHz.
Possible SWO output speeds are:
10MHz, 5MHz, 3.33MHz, ...
J-Link V7: Supported SWO input speeds are: 6MHz / n, n>= 1:
6MHz, 3MHz, 2MHz, 1.5MHz, ...
Permitted combinations are:
SWO output
2MHz, n = 5
1MHz, n = 10
769kHz, n = 13
...
Table 5.8: Permitted SWO speed combinations
J-Link / J-Trace (UM08001)
CHAPTER 5
SWO input
6MHz, n = 10
4MHz, n = 15
...
2MHz, n = 30
...
SWO input
2MHz, n = 3
1MHz, n = 6
750kHz, n = 8
...
Working with J-Link and J-Trace
Deviation percent
0
0
<= 3
0
...
Deviation percent
0
0
2.53
...
