11.3 Getting Started

This chapter presents an introduction to J-Flash SPI. It provides an overview of the
included sample projects and describes the menu structure of J-Flash SPI in detail.
11.3.1 Setup
For J-Link setup procedure required in order to work with J-Flash SPI, please refer to
chapter Setup on page 157
11.3.1.1 What is included?
The following table shows the contents of all subdirectories of the J-Link software and
documentation pack with regard to J-Flash SPI:
Directory
.
.\Doc
.\Samples\JFlash-
SPI\ProjectFiles
Table 11.1: J-Flash SPI directory structure
11.3.2 Using J-Flash SPI for the first time
Start J-Flash SPI from the Windows Start menu. The main window will appear, which
contains a log window at the bottom and the Project window of a default project on
the left. The application log will initially display:
• The version and time of compilation for the application.
• The version and time of compilation for the J-Link DLL.
• The location of the default project.
The Project window contains an overview of the current project settings (initially, a
default project is opened).
J-Link / J-Trace (UM08001)
Contains the J-Flash SPI executable.
Contains the J-Flash SPI documentation.
Contains sample projects for J-Flash SPI.
