Valid attributes
Parameter
Vendor
Name
WorkRAMAddr
WorkRAMSize
Core
JLinkScriptFile
Table 10.1: <ChipInfo> attribute list
Notes
• No separate closing tag. Directly closed after attributes have been specified:
<ChipInfo ... />
• Must not occur outside a <Device> tag.
10.5.3.1 Attrbiute values - Core
The following values are valid for the Core attribute:
• JLINK_CORE_CORTEX_M1
• JLINK_CORE_CORTEX_M3
• JLINK_CORE_CORTEX_M3_R1P0
• JLINK_CORE_CORTEX_M3_R1P1
• JLINK_CORE_CORTEX_M3_R2P0
• JLINK_CORE_CORTEX_M3_R2P1
• JLINK_CORE_CORTEX_M0
• JLINK_CORE_CORTEX_M_V8BASEL
• JLINK_CORE_ARM7
• JLINK_CORE_ARM7TDMI
• JLINK_CORE_ARM7TDMI_R3
• JLINK_CORE_ARM7TDMI_R4
• JLINK_CORE_ARM7TDMI_S
• JLINK_CORE_ARM7TDMI_S_R3
• JLINK_CORE_ARM7TDMI_S_R4
• JLINK_CORE_CORTEX_A8
• JLINK_CORE_CORTEX_A7
• JLINK_CORE_CORTEX_A9
• JLINK_CORE_CORTEX_A12
• JLINK_CORE_CORTEX_A15
J-Link / J-Trace (UM08001)
String that specifies the name of the vendor of the device. This
attribute is mandatory.
E.g. Vendor="ST".
Name of the device. This attribute is mandatory.
E.g. Name="STM32F407IE"
Hexadecimal value that specifies the address of a RAM area that
can be used by J-Link during flash programming etc. Should not
be used by any DMAs on the device. Cannot exist without also
specifying WorkRAMSize. If no flash banks are added for the new
device, this attribute is optional.
E.g. WorkRAMAddr="0x20000000"
Hexadecimal value that specifies the size of the RAM area that
can be used by J-Link during flash programming etc. Cannot exist
without also specifying WorkRAMAddr. If no flash banks are added
for the new device, this attribute is optional.
E.g. WorkRAMSize="0x10000"
Specifies the core that the device incorporates. If a new device is
added, this attribute is mandatory.
E.g. Core="JLINK_CORE_CORTEX_M0"
For a list of valid attribute values, please refer to Attrbiute values
- Core on page 291.
String that specifies the path to a J-Link script file if required for
the device. Path can be relative or absolute. If path is relative, it
is relative to the location of the JLinkDevices.xml file.
This attribute is mandatory.
E.g. JLinkScriptFile="ST/Example.jlinkscript"
Meaning
