18.3 Signal requirements
The table below lists the specifications that apply to the signals as seen at the
JTAG+Trace connector.
Fmax
Ts setup time (min.)
Th hold time (min.)
TRACECLK high pulse width (min.)
TRACECLK high pulse width (min.)
Table 18.1: Signal requirements
J-Link / J-Trace (UM08001)
CHAPTER 18
Signal
200MHz
2.0ns
1.0ns
1.5ns
1.5ns
© 2004-2017 SEGGER Microcontroller GmbH & Co. KG
Designing the target board for trace
Value
