Target menu elements
Command
Connect
Disconnect
Test >
Erase sectors
Erase chip
Program
Program & Verify
Auto
Verify
Read back >
Table 11.5: Target menu elements
Options menu elements
Command
Project settings...
Global settings...
Table 11.6: Options menu elements
J-Link / J-Trace (UM08001)
CHAPTER 11
Creates a connection through the J-Link using the config-
uration options set in the Project settings... of the
Options drop-down menu.
Disconnects a current connection that has been made
through the J-Link.
Two test functions are implemented: "Generates test
data" generates data which can be used to test if the
flash can be programmed correctly. The size of the gen-
erated data file can be defined.
"Tests up/download speed" writes data of an specified
size to a defined address, reads the written data back
and measures the up- and download speed.
Erases all selected flash sectors.
Erases the entire chip.
Programs the chip using the currently active data file.
Programs the chip using the currently active data file and
then verifies that it was written successfully.
The Auto command performs a sequence of steps. It con-
nects to the device, erases sectors and programs the chip
using the currently active data file before the written
data is finally verified. The range of sectors to be erased
can be configured through the Flash tab of the Project
settings dialog and through the Global settings dialog.
Verifies the data found on the chip with the data file.
Reads back the data found on the chip and creates a new
data file to store this information. There are three ways
in which the data can be read back. The Selected sectors
identified on the Flash tab of the Project Settings... found
in the Options drop-down menu may be read back. The
Entire chip may be read back. A specified Range... may
be read back.
Location of the project settings that are displayed in the
snapshot view found in the Project window of the J-Flash
SPI application. Furthermore various settings needed to
locate the J-Link and pass specified commands needed
for chip initialization.
Settings that influence the general operation of J-Flash
SPI.
© 2004-2017 SEGGER Microcontroller GmbH & Co. KG
Description
Description
J-Flash SPI
