DataView™ LI55 Level Controller
Meter Copy or Cloning Instructions
Caution!
1. Connect two meters using a LI56-1000 meter copy cable.
Using standard CAT5 or other cable will cause damage to
both meters. Use LI56-1000 meter copy cable only.
Warning!
2. Do not connect the two meters to the same signal source.
3. Power up both meters. Leave Clone meter in Run Mode.
4. Enter the Advanced Features menu of the Master meter; see
Advanced Features Menu on page 75.
5. Scroll to the Copy function using the Up button then press
Enter.
6. The meter displays the message Send. Press Enter, the display
flashes while sending data. The message done is displayed when
copying is completed.
ENTER
7. The Clone meter displays the message CPY rC while being
programmed then the message done when copying is completed. The
meter initializes and returns to Run Mode using the same settings as
the Master.
8. If meter to be cloned does not respond to the data being sent, refer to
Copy Function Requirements above.
MN301033 Rev B1
Do not connect the two meters to the
!
same signal source while cloning.
Internal calibration may be affected.
ENTER
