DataView™ LI55 Level Controller

INTRODUCTION

The DataView LI55 is a multi-purpose, easy to use digital process meter ideal for
level, flow rate, temperature, or pressure transmitter applications. It accepts
current and voltage signals (e.g. 4-20 mA, 0-10 V). Three of the front panel
buttons can be custom-programmed for a specific operation. The analog input
can be scaled to display the process in two different scales; for example the main
display could indicate level in feet and the second display could indicate the
volume in gallons.
The basic model includes an isolated 24 VDC transmitter power supply that can
be used to power the input transmitter or other devices. An additional isolated
24 VDC power supply is included with the 4-20 mA output option. A digital input
is standard.
A fully loaded LI55 meter has the following: four SPDT relays, 4-20 mA output, and
two 24 VDC power supplies. The LI55 capabilities may be enhanced by adding a
four SPST relays expansion module (creating an eight-relay process meter).
The eight relays can be used for alarm indication or process control applications,
such as pump alternation control. The 4-20 mA isolated output, and digital I/O
options make the LI55 an excellent addition to any system.

ORDERING INFORMATION

Standard Models
85-265 VAC
Model
LI55-1001
LI55-1201
LI55-1011
LI55-1401
LI55-1211
LI55-1411
*Model number for replacement option card.
Accessories
Model
LI56-1400
LI56-1000
LM91-1001
LM91-2001
MN301033 Rev B1
12/24 VDC
Model
LI55-8001
LI55-8201
LI55-8011
LI55-8401
LI55-8211
LI55-8411
Description
4 SPST (Form A) relays
Meter copy cable
Single Display NEMA 4X Enclosure
Dual Display NEMA 4X Enclosure
Options Installed
No options
2 relays (LI56-1201*)
4-20 mA output (LI56-1011*)
4 relays (LI56-1401*)
2 relays & 4-20 mA output (LI56-1211*)
4 relays & 4-20 mA output (LI56-1411*)
Instruction Manual
