Calibrating the Meter with External Source (CAl)

Note: To scale the meter without a signal source
refer to Scaling the Meter (SCALE), page 46.
The meter can be calibrated to display the process variable in engineering units
by applying the appropriate input signal and following the calibration procedure.
The use of a calibrated signal source is strongly recommended to calibrate the
meter.
EN T E R
before performing calibration to ensure specified
MN301033 Rev B1
The displ a y flashes
while sensing
the inputs
EN T ER
EN T ER
Warm up the meter for at least 15 minutes
accuracy.
ENTER
ENTER
Instruction Manual
ENTER
ENTER
ENTER
