Disassembly 4
Removing/Installing the AC Module
Step 1. Remove the top chassis as previously described.
Step 2. Remove the screw using a T10 driver from the rear panel located
beneath the AC receptacle.
Figure 4-15
Step 3. Disconnect the two connections and remove two screws using a
T20 driver from the AC Module.
grey
brown
Figure 4-16
Step 4. Remove the AC Module.
Step 5. To install the AC Module, perform steps 1-4 in reverse order.
