11 Upgrading the 3G module firmware
The next step begins to download the BOOT file through TFTP. The data for the BOOT file version to be teleloaded
appears on the screen, including the file size:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
Upgrading Boot file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15BT C:/WS/FW/F1_2_3_15BT/MSM7200R3/SRC/AMSS 2008/07/09 10:06:20
Firmware size 622640 bytes
A counter then appears giving what percentage of the file has been downloaded and being transmitted to the 3G
module:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
Upgrading Boot file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15BT C:/WS/FW/F1_2_3_15BT/MSM7200R3/SRC/AMSS 2008/07/09 10:06:20
Firmware size 622640 bytes
Upgrading: 13%
Once the BOOT downloading has finished (100%), the 3G module resets so it can continue downloading from the
APP file:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
Upgrading Boot file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15BT C:/WS/FW/F1_2_3_15BT/MSM7200R3/SRC/AMSS 2008/07/09 10:06:20
Firmware size 622640 bytes
Upgrading: 100%
Reseting 3G module
Upgrading Main Application file
Starting firmware upgrade.....
Next, the module resets; this takes approximately 20 seconds:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
Upgrading Boot file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15BT C:/WS/FW/F1_2_3_15BT/MSM7200R3/SRC/AMSS 2008/07/09 10:06:20
Firmware size 622640 bytes
Upgrading: 100%
Reseting 3G module
Upgrading Main Application file
Starting firmware upgrade.....
Reseting 3G module
In the next step, the APP file is downloaded through TFTP and the data for the APP file version appears on the
screen, including the file size:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
Upgrading Boot file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15BT C:/WS/FW/F1_2_3_15BT/MSM7200R3/SRC/AMSS 2008/07/09 10:06:20
Firmware size 622640 bytes
Upgrading: 100%
Reseting 3G module
Upgrading Main Application file
Starting firmware upgrade.....
Reseting 3G module
Upgrading to version F1_2_3_15AP C:/WS/FW/F1_2_3_15AP/MSM7200R3/SRC/AMSS 2008/07/09 13:02:11
Firmware size 18671680 bytes
Now, a counter appears showing the percentage of the file you are downloading and transmitting to the 3G module:
Enter a command>wwanupgrade boot_1.2.3.15.cwe app_1.2.3.15.cwe
82
