- Page 1 Manual Teldat S.A. WWAN Enabler Installation Manual Copyright© Teldat Dm1023-I Version 1.6 02/2023 Teldat S.A. WWAN Enabler...
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Chapter 2 WWAN Enabler ........4 Models ........ - Page 4 Regulatory model “5GE-1” compliance ......B.2.2 Regulatory model “5GE-2” compliance ......WWAN Enabler...
-
Page 5: I Related Documents
Related Documents Teldat S.A. I Related Documents Teldat Dm704-I Configuration and Monitoring Teldat Dm709-I LAN Interfaces Teldat Dm748-I Software Updating Teldat Dm772-I Configuration Interfaces Teldat Dm781-I Cellular Interface Teldat Dm1030-I Teldat WWAN Enabler User Manual WWAN Enabler... -
Page 6: About This Guide
1 About This Guide Teldat S.A. Chapter 1 About This Guide This is the installation guide for the WWAN Enabler. It contains information on how to correctly install the device in a working environment. 1.1 Supported Devices The information included in this installation guide only applies to the WWAN Enabler. - Page 7 1 About This Guide Teldat S.A. Fax: +34 918 076 566 Email: support@teldat.com WWAN Enabler...
-
Page 8: Wwan Enabler
2.2.2 Hardware Monitoring The WWAN Enabler device's hardware is monitored via the LED panel, which provides visual information on what is happening in the device. The LEDs indicate the state of the hardware components, whether or not there is connectiv- ity, data flows, etc. -
Page 9: Components And Power Supply
3 Components and Power Supply Teldat S.A. Chapter 3 Components and Power Supply The following chapter provides detailed information on the WWAN Enabler chassis and its components. This inform- ation includes: • Components. • Information on assembly. • Power supply. -
Page 10: Front Panel
Tricolor Off -> System stopped. Amber -> SIM2 Selected. Green -> SIM1 Selected. 3.1.2 Front Panel The following figure shows the front panel. Here you will find the majority of WWAN Enabler connectors and the SIM card slots. WWAN Enabler... - Page 11 13 for more information on Power con- nection and Power Supply on page 33 for power specifications applicable to the WWAN Enabler device. LAN1/POE 2.5 Gigabit Ethernet. Refer to on page 13 for more information on PoE connection...
-
Page 12: Side Panels
Connecting the WWAN Antennas on page 15 ANT4 WWAN Connector on page 26 Wireless WAN interface (4GePlus) on page 29 Wireless WAN interface (5Ge) on page 32 3.1.4 Underside Panel The following elements can be found on the underside panel: WWAN Enabler... -
Page 13: Assembly
Make sure there is enough space around the device for ventilation purposes and that electricity cables can reach it. WWAN Enabler devices have been equipped with a standard Kensington security slot to which a security cable can be attached. The T-bar lock of the security cable allows the device to be attached to an anchor point, thus preventing potential thefts. -
Page 14: Wall Mounting
Front Panel, side view Fig. 5: 3.2.2 Wall mounting The WWAN Enabler can be mounted on the wall. There are two slots on the underside of the device, used to fix it to the wall. You can see this in Underside Panel page 8. -
Page 15: Ceiling Mounting
Step 2 Hang the device on the screws. 3.2.3 Ceiling mounting To attach the WWAN Enabler device to the ceiling, use the appropriate support (not included, must be ordered sep- arately). Procedure Step 1. -
Page 16: Power Source
Incorrect installation can cause the router to fall from the ceiling and endanger people and equipment. 3.3 Power Source The WWAN Enabler is powered though an external AC/DC source or through an Ethernet cable (provided it com- plies with the POE 802.3at standard). WWAN Enabler... -
Page 17: External Power Source
3.3.2 PoE The WWAN Enabler device can be powered through an Ethernet cable, provided the latter complies with the POE 802.3at standard (PoE+). The LAN1/PoE port is enabled for this. The image below shows how to connect the PoE injector to the device. -
Page 18: Rebooting The Device
IP mask: 255.255.255.0 • Enabler: If you have an Enabler License, the device will have a special configuration. Please see manual Teldat Dm1030-I - WWAN Enabler User Manual for further information on how to access the device and its configuration. -
Page 19: Connecting The Wwan Antennas
Antenna connectors and bands (5Ge) on page 32 Installing these antennas in the WWAN Enabler is essential to improve the quality of the signal received and trans- mitted by the cellular model. Note To achieve good quality performance, the WWAN Enabler device should always have the WWAN an- tennas installed. - Page 20 To achieve optimum performance, the radio frequency accessories installed (antennas and cables) should be those recommended by Teldat. Teldat has a series of accessories (90º mount antennas, antennas for exterior installation, antennas for ceiling install- ation, extension cables, etc.) that allow you to install the devices in different locations.
-
Page 21: Installing The Sim Card
The WWAN Enabler has a Wireless WAN interface that may need a SIM card (or two) to operate. The WWAN Enabler has two protected SIM trays located on its front panel, as shown in the following figure. Fig. 16: SIM trays Fig. - Page 22 Always disconnect the device form the main power supply before installing the SIM cards. Always disconnect the device before removing the casing to access the trays. When inserting the SIM cards, please protect yourself against electrostatic discharges (ESD). Do not touch the SIM card connectors. WWAN Enabler...
-
Page 23: Compliance
4 Compliance Teldat S.A. Chapter 4 Compliance 4.1 Manufacturer Information Brand Teldat Manufacturer Teldat S.A. Country Spain Postal Address Isaac Newton, 10 Parque Tecnológico de Madrid, 28760 Tres Cantos, Madrid, Spain International Phone +34 91 807 65 65 WWAN Enabler... -
Page 24: Safety Warnings
4 Compliance Teldat S.A. 4.2 Safety Warnings WWAN Enabler... - Page 25 4 Compliance Teldat S.A. WWAN Enabler...
-
Page 26: Weee Information
“Teldat Dm704-I Configuration and Monitoring” , low-power-timer command. When the WWAN Enabler is not needed, it can also be turned off disconnecting the power supply to save energy. 4GePlusmodel: Network Standby power consumption: 5.32 W. -
Page 27: Psu Energy Efficiency
Richtlinie 2009/125/EG (ErP) Richtlinien 2011/65/EU und 2015/863/EU (RoHS) des Europäischen Parlaments. Spanish (ES) Español Por la presente, Teldat S.A. declara que el tipo de equipo radioeléctrico WWAN Enabler es conforme con: Directiva 2014/53/UE (RED) Directiva 2009/125/CE (ErP) Directivas 2011/65/UE y 2015/863/UE (RoHS) del Parlamento Europeo y del Consejo. -
Page 28: Ce Marking
34. 4.11 Intended use of the equipment The WWAN Enabler can be deployed as a Customer Premises Equipment (CPE) in enterprise branch offices or in environments managed by the service provider. This product must only be used indoors. -
Page 29: Appendix A Technical Information
A.2 Updating the software The WWAN Enabler can be updated to new releases. Please contact your distributor for further details on new re- leases. Firmware updating is carried out through a traditional FTP file transfer. For further information on updating firmware through FTP, please see manual Teldat-Dm748-I Software Updating, section 1.3 FTP Updating. -
Page 30: Connectors
POE+(B) BI-DB- BI-DB- POE-(A) BI-DD+ POE-(B) BI-DD- POE-(B) A.3.2 WWAN Connector The WWAN Enabler has up to four SMA female connectors installed. Internal RF in/out External A.3.3 Power Supply Connector Jack 5.5/2.5mm Internal -> POSITIVE External -> NEGATIVE WWAN Enabler... -
Page 31: Technical Specifications
A.4 Technical Specifications A.4.1 Hardware Architecture PROCESSORS NXP LayerScape multicore processor. MEMORY DDR4 1 GBytes. STORAGE UNIT FLASH Memory 32 MBytes. A.4.2 LAN Interface PROTOCOLS Ethernet (802.3). PORTS Port managed with MDI/MDX autodetection. SPEED 10/100/1000/2500 Mbps (BaseT). CONNECTOR RJ45 female. WWAN Enabler... - Page 32 • WCDMA: • 3GPP Release 9 • B2, B4, B5 Speed (DL/UL) The data rates presented are theoretical only, and the actual value depends on network condition. EM06-E, EM06-A • LTE Cat 6. • FDD. 300Mbps/50Mbps • TDD: 222Mbps/26Mbps WWAN Enabler...
-
Page 33: Wireless Wan Interface (4Geplus)
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V) ANTENNA Devices equipped with this interface are shipped with two multi-band swivel-mount dipole antennas. A.4.3.1 Antenna connectors (4GePlus) Antenna connectors Connector ANT4 ANT3 ANT2 ANT1 Diversity (RX) Main (TX/RX) WWAN Enabler... - Page 34 • Network Options: Option 2 for SA and Option 3/3a/3x for NSA EN-DC. DSS supported in all FDD bands • EN-DC Combinations: Up to 5DL + 1FR1 and 2DL + 2FR1. • UL modulation: 256QAM for FR1. • DL modulation: 256QAM for FR1. WWAN Enabler...
- Page 35 • DL Cat 20: up to 20 layers (Up to 2Gbps) • UL Cat 18: 2CC intra-band contiguous and inter-band, 256QAM (Up to 210 Mbps) • Supported BW: 1.4–20 MHz, per 3GPP specs for supported bands • HSPA+ Cat 24/6: 42Mbps/5.76Mbps RM520N-GL: • 5G-NR WWAN Enabler...
-
Page 36: Wireless Wan Interface (5Ge)
• MHB (Middle High Band): 1452–2690 MHz • UHB (Ultra High Band): 3400–3800 MHz • n77/n78: 3300–4200 MHz • n79: 4400–5000 MHz • LAA (License Assisted Access): 5150-5925 MHz • TX: Transmit • PRX: Primary Reception • DRX: Diversity Reception WWAN Enabler... -
Page 37: Power Supply
LENGTH x WIDTH x HEIGHT 196.33 x 196.33 x 54.93 mm. WEIGHT 0.4 kg. A.4.7 Environmental Specifications TEMPERATURE OPERATING NORMALLY: 0 ºC to 45 ºC STORED: -25 ºC to 70 ºC RELATIVE HUMIDITY On: 5 % to 90 % WWAN Enabler... -
Page 38: Appendix B Radio Information
Rx: 2110–2200 MHz Technology: UMTS(WCDMA)/ HSDPA/ HSUPA/ HSPA+/ DC-HSPA+. Bands Frequencies Conducted Transmit Power Band 1 Tx: 1920-1980 MHz +24 dBm +1/-3 dB Rx: 2110-2170 MHz Band 2 Tx: 1850-1910 MHz +24 dBm +1/-3 dB Rx: 1930-1990 MHz WWAN Enabler... -
Page 39: Rf Wan (5G Models) Specifications
Band 1 Tx: 1920-1980 MHz +23 dBm ± 2 dB Rx: 2110-2170 MHz Band 3 Tx: 1710–1785 MHz +23 dBm ± 2 dB Rx: 1805–1880 MHz Band 7 Tx: 2500–2570 MHz +23 dBm ± 2 dB Rx: 2620–2690 MHz WWAN Enabler... -
Page 40: Regulatory Model "5Ge-1" Compliance
B.2.1 Regulatory model “5GE-1” compliance The conformity assessment procedure mentioned in Article 17 and detailed in Annex III of Directive 2014/53/EU has been verified when it comes to the WWAN Enabler with Regulatory Model "5GE-1" using the following technologies and bands: •...
