5 Monitoring via the console in generic mode
*monitor
Console Operator
+protocol l2tp
L2TP+tunnel-info all
RemoteIP:172.24.78.28
RemoteName:01.03-EthAnt-00
LocalID:60833
group 2
Pseudowire:
LAC LocalID:19804
LastChange:12s
encaps:4
For a Cisco router configured with PPPoE, run the show ppoe session and show pppoe session all commands to
view the status of the PPPoE session:
Cisco-Teldat-3Ge#show pppoe session
1 client sessions
Uniq ID PPPoE
SID
N/A
Cisco-Teldat-3Ge#
Cisco-Teldat-3Ge#show pppoe session all
Total PPPoE sessions 1
session id: 1
local MAC address: 0012.7f7e.5f4d, remote MAC address: 00a0.2619.0184
virtual access interface: Vi2, outgoing interface: Fa0/1
11477 packets sent, 6348 received
1166636 bytes sent, 2975319 received
Cicso-Teldat-3Ge#
For a Cisco router configured with L2TP, the show l2tun command is used to view the state of an L2TP session:
%No active L2F tunnels
L2TP Tunnel and Session Information Total tunnels 1 sessions 1
LocID RemID Remote Name
54565 64091 01.03-EthAnt- est
LocID RemID
546 37140
%No active PPTP tunnels
When the state isn't State:established (State est for the Cisco), there is probably no access to the Teldat-3Ge-USB
device (DHCP has not terminated correctly). To check this (for a Teldat Router), access the DHCP monitoring menu
and check the assigned addresses (leases command):
========================================
..:: Currently assigned DHCP Leases ::..
========================================
172.24.78.28
For a Cisco router, the assigned addresses can be viewed by running show ip dhcp pool:
Pool ethant :
Utilization mark (high/low)
Subnet size (first/next)
Total addresses
Leased addresses
Pending event
0 subnet is currently in the pool :
Current index
172.24.78.30
36
LocalIP:0.0.0.0
State:established
RemoteID:60997 Sessions:1
Interface:l2tp1 Sequencing:off
RemoteID:9722 State:established
Events:Show
decaps:0 missed:0
RemMAC Port
LocMAC
1 00a0.2619.0184 Fa0/1
0012.7f7e.5f4d
State Remote Address
172.24.78.30
TunID Username, Intf/
Vcid, Circuit
54565 20, Vp1
hardware ethernet 00:a0:26:fe:98:89
start Thu Sep 06 2007 11:25:55
uid 'teldat'
: 100 / 0
: 0 / 0
: 1
: 1
: none
IP address range
172.24.78.30 - 172.24.78.30
Port:1701
dropped:0
Source VA
VA-st
Di1 Vi2
UP
Port Sessions L2TP Class/
1701 1 l2tpclass1
State Last Chg Uniq ID
est 00:00:52 1
end Thu Sep 06 2007 23:25:55
Leased addresses
1
State
UP
