3 Configuring in Generic mode

Chapter 3 Configuring in Generic mode

This mode allows you to connect either a Teldat or Cisco router, or a router from a different manufacturer, to a 3G
network through the Teldat-3Ge-USB. Here we describe how to configure the router in these cases.

3.1 Configuring a Cisco router with PPPoE

Connecting a Cisco router to a WWAN mobile network through the Teldat-3Ge-USB with PPPoE is performed
through a dialer interface
Note
We recommend using version IOS 12.4.3 or above with Cisco devices. From this version onwards, op-
erations can be guaranteed with the Teldat-3Ge-USB.
We recommend using PPPoE rather than L2TP to connect a Cisco router to a Teldat-3Ge-USB.
The Cisco router establishes PPP communications with the WWAN network over a PPPoE session through the
dialer interface
Fig. 9: PPPoE session in generic mode with a Cisco router
Here is a guideline configuration for connecting a Cisco router through the Teldat-3Ge-USB:
version 12.4
service timestamps debug datetime msec
service timestamps log datetime msec
no service password-encryption
!
hostname Cicso-Teldat-3Ge
!
boot-start-marker
boot-end-marker
!
logging buffered 4096 informational
no logging console
enable secret 5 $1$HZK4$PbeK/a3IWoFJW.6zG9feA/
enable password teldat
!
no aaa new-model
ip subnet-zero
ip cef
!
!
!
ip dhcp pool ethant
host 172.24.78.28 255.255.0.0
client-identifier 7465.6c64.6174
bootfile fwethant.img
