OPTIONS:
version,
l2tp,
pppoe,
ipconfig,
call,
cell,
usb,
Enter a command>
The available options are as follows:
version
l2tp
pppoe
ipconfig
call
cell
usb
<cr>
Examples of the results for the commands depending on the different options:
• showmonitor version:
Enter a command>showmonitor version
Running version: Sep 17 16:57:51 2008#01.08vEthAnt-00
Flash version: Sep 17 16:57:51 2008#01.08vEthAnt-00
Power supply: EXTERNAL
Power supply on reset: POE
Manufacturer: Sierra Wireless, Inc.
Model: MC8775V
Revision: H1_1_8_14MCAP C:/WS/FW/H1_1_8_14MCAP/MSM6280/SRC 2007/07/13 16:35:30
IMEI: 352679010001472
IMEI SV: 9
FSN: X301956006210
3GPP Release 5
+GCAP: +CGSM,+DS,+ES
IMEI:
352679010001472
IMSI:
214072433009016
ICCID: 8934074193012672404F
Enter a command>
• showmonitor l2tp:
Enter a command>showmonitor l2tp
==============================================
Sep 19 02:42:40 l2tpd[1735]: [ppp]IPCP
Sep 19 02:42:40 l2tpd[1735]: [ppp]IPCP
Sep 19 02:42:40 l2tpd[1735]: [ppp]IPCP
RemoteIP:172.24.80.13
RemoteName:ATLAS
LocalID:36158
Pseudowire:ETH-ANT-PPP
LNS LocalID:25276
LastChange:5m 47s
encaps:17
bytesencaps:826
error encaps:0
Teldat-3Ge-USB User Manual
Show version information
Show l2tp information
Show pppoe information
Show ip configuration information
Show call information
Show cell information
Show usb interface information
Displays information on the device firmware version and the WWAN modem para-
meters.
Information on the L2TP tunnels.
Information on the PPPoE session.
Information on the device IP configuration obtained through DHCP.
Information on the state of the HSDPA/HSUPA networks connectivity and the RF
signal level.
Information on the cell the device is connected to.
Information on the WWAN modem USB interfaces.
All the above options are displayed.
LocalIP:0.0.0.0 Port:1701
State:established
RemoteID:39370 Sessions:1
Interface:/dev/ttyUSB4
RemoteID:44780 State:established
decaps:11
bytesdecaps:295
error decaps:0
Address 88.29.114.99
Address 88.29.114.99
Address 88.29.114.99
Sequencing:off
missed:0 dropped:0
crc errors:0
7 Monitoring the device via Telnet
