8 Configuring various devices on the same Ethernet
!
!
ip classless
ip route 0.0.0.0 0.0.0.0 Virtual-PPP1
!
!
ip http server
no ip http secure-server
ip nat inside source list 1 interface Virtual-PPP1 overload
ip nat inside source list 1 interface Virtual-PPP2 overload
!
access-list 1 permit any
access-list 2 permit 172.24.78.31
access-list 2 permit 172.24.78.32
!
!
!
tftp-server flash:fwethant.img 2
!
control-plane
!
!
line con 0
line aux 0
line vty 0 4
password cisco
login
!
end
In the global configuration of the Teldat router in generic mode with PPPoE, specify 2 PPP interfaces. Each one of
these has a different service-name in the PPPoE configuration: ethant and ethantaux. This means each PPP inter-
face connects through one of the Teldat-3Ge-USB devices.
log-command-errors
no configuration
set hostname ATLAS
add device ppp 1
add device ppp 2
;
network ethernet0/0
; -- Ethernet Interface User Configuration --
ip address 172.24.78.29 255.255.0.0
;
exit
;
network ppp1
; -- Generic PPP User Configuration --
ip address unnumbered
;
ppp
; -- PPP Configuration --
authentication sent-user internet password internet
ipcp local address assigned
no ipcp peer-route
exit
;
base-interface
; -- Base Interface Configuration --
base-interface ethernet0/0 link
;
exit
;
pppoe
; -- PPPoE User Configuration --
enable pppoe
ac-name ethant
70
