Monitors and Cameras

Connecting Monitors

Using a Desktop System as the Monitor for a Computer

If you have a set-top or component system, you need to connect a monitor to
the system to see the people at the far site. Refer to your system's setup sheet
for connection details. The following table shows the different ways you can
connect monitors to a VSX system. The main monitor is the monitor that
displays the VSX system user interface.
VSX System
VSX 5000, VSX 6000, VSX 6000A,
VSX 7000, VSX 7000s, VSX 7000e,
VSX 8000
VSX 5000, VSX 6000, VSX 6000A,
VSX 7000, VSX 7000s, VSX 7000e,
VSX 8000
VSX 5000, VSX 6000, VSX 6000A,
VSX 7000, VSX 7000s, VSX 7000e,
VSX 8000
VSX 5000, VSX 6000A
VSX 7000s, VSX 7000e, VSX 8000
*Requires an additional display adapter on the VSX 6000 and VSX 7000.
You can use the VSX 3000 or VSX 3000A system as a high-resolution XGA
display for your computer, as shown on the system setup sheet.
To use the VSX 3000 or VSX 3000A system as the monitor for a computer:
1. Connect the VGA cable from the VGA connector on the back of the
VSX 3000 or VSX 3000A system to the VGA connector on your computer.
2. To use the system's built-in speakers for your computer's audio, connect
an audio cable from your computer to the audio input connector on the
left side of the VSX 3000 or VSX 3000A system.
Main Monitor Second Monitor
TV (NTSC or PAL) None
TV (NTSC or PAL) TV (NTSC or PAL)*
TV (NTSC or PAL) VGA monitor*
VGA monitor Not available
VGA monitor TV (NTSC or PAL)
3
3 - 1
