Monitors and Cameras

Connecting Monitors

Make sure that the system is powered off before you connect devices.
The following table shows how you can connect monitors to a Polycom QDX
6000 system.
Video Output Number
1
2
The Polycom QDX 6000 system user interface is displayed on Monitor 1.
For Monitor 2, the system provides RCA, S-Video, and VGA connectors. Only one
at a time is active, based on the output format configured for that monitor.
Connector Output Formats
RCA (three) YPrPb
RCA (yellow) Composite
S-Video S-Video
RCA (yellow) Composite
S-Video S-Video
VGA VGA
