Administrator's Guide for the VSX Series

PRI Network Interface Status Lights

Serial V.35/RS-449/RS-530 Network Interface Status Lights

2 - 18
When the BRI network interface...
Indicators are off
Green indicator is on
Yellow indicator is on
Green and yellow indicators are on
The PRI network interface module is available for VSX 7000, VSX 7000s,
VSX 7000e, and VSX 8000 systems.
When the PRI network interface...
Indicators are off
Red indicator is on or blinking
Yellow indicator is on or blinking
Green indicator is on
The serial V.35/RS-449/RS-530 network interface module is available for
VSX 7000, VSX 7000s, VSX 7000e, and VSX 8000 systems.
It means...
• No power to the system, or
• The system is not connected to the
network, or
• The system is not receiving a clock
signal from the network, or
• The system is restarting.
The system is receiving a clock signal
from the network.
The system is able to make a call.
• The system is receiving a software
update, or
• The system is operating normally.
It means...
No power to the system.
The system is not connected to the
ISDN network, or there is a problem
with the ISDN line.
There is a problem with the ISDN line.
The system is able to make and receive
calls.
