Connecting Speakers to Component Systems

Placing Speakers to Play Stereo from Far Sites

You must connect at least one speaker to play audio from the far site. You can
use the speakers built into the main monitor, or you can connect an external
speaker system such as the Polycom StereoSurround kit to provide more
volume and richer sound in large rooms. Refer to your system's setup sheet for
connection details.
The Polycom StereoSurround kit is designed for use with VSX systems. It
includes two speakers and a subwoofer. If you do not choose to connect
external speakers, you can use your monitor's speakers to receive stereo.
You cannot receive stereo with a set-top VSX system using the system's
built-in speaker.
When you set up the system for StereoSurround, the left microphone and
speaker should be on the left from the local room perspective. Place the
speaker connected to the audio system's right channel on the right side of the
system, and the other speaker on the left side. The system reverses the left and
right channels for the far site, as shown in the following illustration. This
ensures that the sound comes from the appropriate side of the room.
Left
Right
Sending stereo
Microphones and Speakers
Right
Left
Receiving stereo
4 - 7
