Monitors and Cameras

Connecting Monitors

The following table shows how you can connect monitors to a Polycom HDX
system. The monitor connected to video output 1 displays the Polycom HDX
system user interface.
Video Output Number
1
2
3 (VCR/DVD Player)
4 (Content)
For Monitor 1 and Monitor 2, the system provides both dual BNC connectors
and a DVI-I connector. Only one at a time is active. If both outputs are
connected to monitors, only the DVI-I connector is active.
Connector Output Formats
BNC (two) S-Video, Composite
DVI-I VGA, DVI, HDMI, Component
BNC (two) S-Video, Composite
DVI-I VGA, DVI, HDMI, Component
BNC (two) S-Video, Composite
DVI-I VGA, DVI, HDMI, Component
