Revolabs Single Channel System - Polycom VSX7000e Setup Guide

OTES A ND

A UTIONS

This setup guide will guide you through the steps needed to properly connect a

Revolabs Single Channel System to a Polycom VSX7000e video codec.

1. Connecting the Cables

2. Configuring the VSX7000e Video Codec

It is important to carefully follow these instructions in order and completely.

Note:

Otherwise your Single Channel System and/or the video codec may not function

properly. Please read through these instructions completely before proceeding.

Contact Revolabs technical support if you have any questions.

Requirements for connecting systems:

1. Revolabs Single-Channel System

2. Revolabs 2.5mm to RCA Audio Cable (included with Single -Channel)

3. Polycom VSX7000e video codec

Table of Contents

Need help?

Do you have a question about the VSX7000e and is the answer not in the manual?

Page 1 OTES A ND A UTIONS This setup guide will guide you through the steps needed to properly connect a Revolabs Single Channel System to a Polycom VSX7000e video codec. 1. Connecting the Cables 2. Configuring the VSX7000e Video Codec It is important to carefully follow these instructions in order and completely.
Page 2 ONFIGURI NG THE A UDIO MENUS OF THE VIDEO CODEC 1. Select SYSTEM 2. Select ADMIN SETTINGS 3. Select AUDIO 4. Set Red LINE INPUT to AUDIO MIXER 5. ENABLE Echo Canceller 6. DISABLE Polycom microphones by removing checkmark on ENABLE POLYCOM MICROPHONES...
