Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)

Output signal checks

MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Model
≥ 4 GHz models
< 4 GHz models
■ Now fine adjust the generator output until the Ch 1 Amplitude
readout indicates the amplitude is as follows (readout may fluctuate):
Model
≥ 4 GHz models
< 4 GHz models
■ Disconnect the cable at Aux In and reconnect it to Aux In through
an attenuator:
Model
≥ 4 GHz models
< 4 GHz models
g. Repeat step 4.f only, for the full bandwidth selected.
NOTE. You just checked the trigger sensitivity. If desired, you may repeat
steps 1 through step 4.c for the other channels (Ch 2, Ch 3, and Ch 4).
5. Disconnect the hookup: Disconnect the equipment from Aux In and the
channel last tested.
The procedure that follows checks those characteristics of the output signals that
are listed as checked under Warranted Characteristics in Specifications.
Amplitude
7 divisions
7 divisions
Amplitude
700 mV
700 mV
Attenuator
2X
2X
