Specifications (MSO/DPO5000/B Series)

Analog channel input and vertical specification

Number of input channels
Input coupling
Input resistance selection
Input impedance DC coupled
1 MΩ
50 Ω
Input capacitance 1MΩ DC coupled 13 pF ± 2 pF
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
This chapter contains specifications for the MSO5000/B and DPO5000/B series
oscilloscopes. All specifications are guaranteed unless noted as "typical." Typical
specifications are provided for your convenience but are not guaranteed.
Specifications that are marked with the
Verification.
All specifications apply to all MSO5000/B and DPO5000/B models unless noted
otherwise. To meet specifications, two conditions must first be met:
■ The instrument must have been operating continuously for twenty minutes
within the specified operating temperature range.
■ You must perform the Signal Path Compensation (SPC) operation before
evaluating the instrument's performance to the specifications. (See page 4-32,
Self Test.) If the operating temperature changes by more than 10 °C (18 °F),
perform the SPC operation again.
4 analog channels, digitized simultaneously
DC or AC
1 MΩ or 50 Ω
250 kΩ selectable for performance verification.
1 MΩ ±1%
50 Ω ±1%
MSO5204/B,
DPO5204/B
MSO5104/B,
DPO5104/B
MSO5054/B,
DPO5054B
MSO5034/B,
DPO5034/B
symbol are checked in Performance
VSWR ≤1.5:1 from DC to 2 GHz, typical
VSWR ≤1.5:1 from DC to 1 GHz, typical
VSWR ≤1.5:1 from DC to 500 MHz, typical
VSWR ≤1.5:1 from DC to 350 MHz, typical
