Tektronix MSO70000C/DX Technical Reference page 43

Vertical system analog channels (cont.)
series)
MSO/DPO72004C 9 GHz
MSO/DPO71604C
MSO/DPO71254C
where applicable
Gain Setting, full scale
100 mV 0.46 mV
150 mV 0.63 mV
200 mV 0.71 mV
300 mV 1.03 mV
400 mV 1.33 mV
500 mV 1.57 mV
600 mV 1.89 mV
700 mV 2.21 mV
800 mV 2.21 mV
900 mV 2.86 mV
1.0 V 3.55 mV
2.0 V 6.55 mV
2.5 V 7.92 mV
3.0 V 9.30 mV
4.0 V 13.01 mV
4.5 V 14.50 mV
5.0 V 15.98 mV
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
8 GHz 7 GHz
0.45 mV 0.43 mV
0.60 mV 0.57 mV
0.67 mV 0.63 mV
0.99 mV 0.95 mV
1.27 mV 1.18 mV
1.48 mV 1.41 mV
1.79 mV 1.71 mV
2.11 mV 2.01 mV
2.11 mV 2.01 mV
2.74 mV 2.61 mV
3.36 mV 3.18 mV
6.33 mV 5.94 mV
7.63 mV 7.20 mV
8.93 mV 8.46 mV
12.40 mV 11.81 mV
13.80 mV 13.17 mV
15.20 mV 14.53 mV
6 GHz 5 GHz
0.40 mV 0.37 mV
0.54 mV 0.51 mV
0.60 mV 0.57 mV
0.89 mV 0.84 mV
1.10 mV 1.06 mV
1.31 mV 1.22 mV
1.60 mV 1.49 mV
1.88 mV 1.76 mV
1.88 mV 1.76 mV
2.45 mV 2.29 mV
2.99 mV 2.77 mV
5.51 mV 5.28 mV
6.68 mV 6.34 mV
7.84 mV 7.40 mV
11.07 mV 10.37 mV
12.34 mV 11.53 mV
13.61 mV 12.68 mV
4 GHz
0.34 mV
0.48 mV
0.53 mV
0.77 mV
0.98 mV
1.10 mV
1.35 mV
1.59 mV
1.59 mV
2.08 mV
2.65 mV
4.90 mV
5.83 mV
6.77 mV
9.51 mV
10.54 mV
11.57 mV
31
