Vertical system analog channels (cont.)
series)
MSO/DPO73304DX
MSO/DPO72504DX
MSO/DPO72304DX
Analog bandwidth ≥4 GHz,
≤20 GHz models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
The MSO/DPO73304DX, MSO/DPO72504DX, and MSO/DPO72304DX instrument bandwidths
with BWE disabled are typical.
BW settings
No BWE
33 GHz BWE
23 GHz BWE
BW settings
No BWE
25 GHz BWE
23 GHz BWE
BW settings
No BWE
23 GHz BWE
Typical temperature derating
Frequency
DC — 5 GHz
10 GHz
15 GHz
20 GHz
25 GHz
30 GHz
33 GHz
DC 50 Ω coupling, full bandwidth, TCA-292mm or TCA-N adapter, operating ambient temperature
15 °C to 40 °C (59 °F to 104 °F).
Enhanced bandwidth only applies to full scale (FS) settings of 100 mV, 200 mV, 500 mV, 1 V, and
2.5 V. Enhanced bandwidth of 4 GHz, 6 GHz, and 8 GHz is only available at 25 GS/s and 50 GS/s.
Use the Temperature variation table to determine the amount of performance derating above the
temperature limit.
Bandwidth
DC to >33 GHz, typical
DC to >33 GHz
DC to >23 GHz
Bandwidth
DC to >25 GHz, typical
DC to >25 GHz
DC to >23 GHz
Bandwidth
DC to >23 GHz, typical
DC to >23 GHz
TC, (dB/°C)
0.005 dB/°C
0.010 dB/°C
0.025 dB/°C
0.045 dB/°C
0.065 dB/°C
0.115 dB/°C
0.160 dB/°C
Sample rate
All
100 GS/s
50 GS/s
Sample rate
All
100 GS/s
50 GS/s
Sample rate
50, 100 GS/s
50, 100 GS/s
