Tektronix MSO70000C/DX Technical Reference page 148

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC voltage measurement accuracy (averaged), ≥4 GHz, ≤20 GHz models
Instrument performance test
Ch4 10 mV Vert scale setting,
-5 Div position setting, +0.45 V offset
Ch4 10 mV Vert scale setting,
+5 Div position setting, -0.45 V offset
Ch4 20 mV Vert scale setting,
-5 Div position setting, +0.4 V offset
Ch4 20 mV Vert scale setting,
+5 Div position setting, -0.4 V offset
Ch4 50 mV Vert scale setting,
-5 Div position setting, +0.25 V offset
Ch4 50 mV Vert scale setting,
+5 Div position setting, -0.25 V offset
Ch4 100 mV Vert scale setting,
-5 Div position setting, +2.0 V offset
Ch4 100 mV Vert scale setting,
+5 Div position setting, -2.0 V offset
Ch4 200 mV Vert scale setting,
-5 Div position setting, +1.25 V offset
Ch4 200 mV Vert scale setting,
+5 Div position setting, -1.25 V offset
Ch4 500 mV Vert scale setting,
-5 Div position setting, 0 V offset
Ch4 500 mV Vert scale setting,
+5 Div position setting, 0 V offset
DC voltage measurement accuracy (averaged), <4 GHz models, 50 Ω
Instrument performance test
Ch1 1 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch1 1 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch1 2 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch1 2 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch1 5 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch1 5 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
Ch1 10 mV Vert scale setting,
-5 Div position setting, +0.5 V offset
Ch1 10 mV Vert scale setting,
+5 Div position setting, -0.5 V offset
136
Minimum
+ 524.75 mV
- 535.25 mV
+ 552.75 mV
- 567.25 mV
+ 636.75 mV
- 663.25 mV
+ 2.764 V
- 2.836 V
+ 2.697 V
- 2.803 V
+ 3.394 V
- 3.606 V
Minimum
+ 504.24 mV
- 509.76 mV
+ 512.97 mV
- 519.03 mV
+ 536.26 mV
- 543.74 mV
+ 574.19 mV
- 585.81 mV
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Incoming Outgoing
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
__________ __________
Maximum
+ 535.25 mV
- 524.75 mV
+ 567.25 mV
- 552.75 mV
+ 663.25 mV
- 636.75 mV
+ 2.836 V
- 2.764 V
+ 2.803 V
- 2.697 V
+ 3.606 V
- 3.394 V
Maximum
+ 509.76 mV
- 504.24 mV
+ 519.03 mV
- 512.97 mV
+ 543.74 mV
- 536.26 mV
+ 585.81 mV
- 574.19 mV
