Random Noise, Sample Acquisition Mode
Performance checks
Bandwidth
Channel 3
Full
250 MHz limit
20 MHz limit
Channel 4
Full
250 MHz limit
20 MHz limit
Random Noise, Sample Acquisition Mode
Performance checks
Bandwidth
MSO5204B, DPO5204B
Channel 1
Full
250 MHz limit
20 MHz limit
Channel 2
Full
250 MHz limit
20 MHz limit
Channel 3
Full
250 MHz limit
20 MHz limit
Channel 4
Full
250 MHz limit
20 MHz limit
MSO5104B, DPO5104B
Channel 1
Full
250 MHz limit
20 MHz limit
Channel 2
Full
250 MHz limit
20 MHz limit
Channel 3
Full
250 MHz limit
20 MHz limit
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Performance verification (MSO/DPO5000/B series)
Vertical sensitivity = 100 mV/div
1 MΩ
Test result (mV)
High limit (mV)
8.13
6.10
4.10
8.13
6.10
4.10
Vertical sensitivity = 100 mV/div
1 MΩ
Test result (mV)
High limit (mV)
6.1
3.7
3.1
6.1
3.7
3.1
6.1
3.7
3.1
6.1
3.7
3.1
4.5
3.7
3.0
4.5
3.7
3.0
4.5
3.7
3.0
50 Ω
Test result (mV)
High limit (mV)
8.13
6.10
4.10
8.13
6.10
4.10
50 Ω
Test result (mV)
High limit (mV)
5.0
3.8
4.0
5.0
3.8
4.0
5.0
3.8
4.0
5.0
3.8
4.0
4.5
3.8
4.0
4.5
3.8
4.0
4.5
3.8
4.0
301
