Analog channel input and vertical specification (cont.)
Delay between channels, full
bandwidth, typical
Deskew range
Crosstalk channel isolation
TekVPI interface
Total probe power
Probe power per channel
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
MSO/DPO5054B
Vertical Setting
1 V/div
≤100 ps between any two channels with input impedance set to 50 Ω, DC coupling, with equal
volts/division setting or above 10 mV/div
All settings in the instrument can be manually time aligned using the Probe Deskew function
–75 ns to +75 ns
≥100:1 at ≤100 MHz and ≥30:1 at >100 MHz up to the rated bandwidth for any two channels
having equal Volts/Div settings
The probe interface allows installing, powering, compensating, and controlling a wide range of
probes offering a variety of features.
The interface is available on all front panel inputs including Aux In. Aux In only provides 1 MΩ input
impedance and does not offer 50 Ω as the other input channels do.
Five TekVPI-compliant probe interfaces (one per channel)
15 W maximum internal probe power (12 W maximum with firmware versions <6.4.0)
Provision for 50 W probe power with 119-7465-00 TekVPI External Power Supply
Voltage
5 V
12 V
Specifications (MSO/DPO5000/B Series)
50 Ω termination
Full BW 250 MHz BW
50.0 50.0
Max Amperage
50 mA (250 mW)
2 A (24 W)
20 MHz BW
40.0
Voltage Tolerance
±5%
±10%
