Tektronix MSO70000C/DX Technical Reference page 161

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC gain accuracy (averaged), >20 GHz models
Instrument performance test
Ch2 20 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -2.5 V offset
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
Ch2 50 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -2.5 V offset
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Minimum Incoming
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 117.6 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
+ 294 mV __________
Outgoing Maximum
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 122.4 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
__________ + 306 mV
149
