Tektronix MSO70000C/DX Technical Reference page 23

Vertical system analog channels (cont.)
series)
Analog bandwidth 50 Ω DC
coupled <4 GHz models
DPO7354C
DPO7254C
DPO7104C
DPO7054C
Analog bandwidth 1 MΩ DC
coupled <4 GHz models
Analog bandwidth with TAP2500
VPI probe, typical, DPO7254C
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
Note: The DPO7354C is guaranteed 3.5 GHz bandwidth with BWE On and can be verified with a 4-
division sine wave. Typical bandwidth when measured with an 8-division sine wave is 3 GHz.
SCALE range
10 mV/div to 1 V/div
5 mV/div to 9.99 mV/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
SCALE range
10 mV/div to 1 V/div
5 mV/div to 9.99 mV/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
SCALE range
5 mV/div to 1 V/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
SCALE range
5 mV/div to 1 V/div
2 mV/div to 4.99 mV/div
1 mV/div to 1.99 mV/div
Full bandwidth, operating ambient temperature of ≤ 30 °C (86 °F), derated by 1% for each °C
above 30 °C (86 °F)
SCALE range
5 mV/div to 10 V/div
2 mV/div to 4.98 mV/div
1 mV/div to 1.99 mV/div
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
SCALE range
≥ 100 mV/div
50 mV/div to 99.5 mV/div
20 mV/div to 49.8 mV/div
10 mV/div to 19.9 mV/div
Bandwidth
DC to 3.5 GHz, BWE on
DC to 2.5 GHz, BWE off
DC to 2.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
Bandwidth
DC to 2.5 GHz
DC to 2.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
Bandwidth
DC to 1.0 GHz
DC to 500 MHz, typical
DC to 200 MHz, typical
Bandwidth
DC to 500 MHz
DC to 400 MHz, typical
DC to 200 MHz, typical
Bandwidth
DC to 500 MHz, typical
DC to 350 MHz, typical
DC to 175 MHz, typical
Bandwidth
DC to 2.5 GHz
DC to 2.0 GHz
DC to 500 MHz
DC to 200 MHz
11
