Horizontal and acquisition system (cont.)
series)
Maximum record length, sample
mode <4 GHz models
Standard, DPO7354C and
DPO7254C
DPO7104C
DPO7054C
Option 2RL installed,
DPO7354C and DPO7254C
DPO7104C
DPO7054C
Option 5RL installed,
DPO7354C and DPO7254C
DPO7104C
DPO7054C
Option 10RL installed,
DPO7354C and DPO7254C
Maximum record length, HiRes
mode
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
The maximum record length depends on the number of active channels and the record length
options installed. Maximum record length is less in serial trigger mode, hi-res mode or when using
the FIR filter.
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
5 GS/s
10 GS/s or less
20 GS/s or less
2.5 GS/s
5 GS/s or less
10 GS/s or less
10 GS/s
20 GS/s or less
40 GS/s or less
Half the record length of sample mode
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
12,500,000 points (3 or 4 channels)
25,000,000 points (2 channels)
50,000,000 points (1 channel)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
25,000,000 points (3 or 4 channels)
50,000,000 points (2 channels only)
125,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
50,000,000 points (3 or 4 channels)
125,000,000 points (2 channels only)
250,000,000 points (1 channel only)
125,000,000 points (3 or 4 channels)
250,000,000 points (2 channels only)
500,000,000 points (1 channel only)
