Tektronix MSO70000C/DX Technical Reference page 305

DC Gain Accuracy
Performance checks Bandwidth
Channel 4 DC Gain 20 MHz
Accuracy, 0 V offset,
0 V vertical position,
50 Ω
250 MHz
FULL
Channel 4 DC Gain 20 MHz
Accuracy, 0 V offset,
0 V vertical position,
1 MΩ
250 MHz
FULL
DC Offset Accuracy
Performance checks Vertical scale
All models:
Channel 1 DC Offset 1 mV/div
Accuracy, 20 MHz
1 mV/div
BW, 50 Ω
100 mV/div
100 mV/div
1
Use this value for both the calibrator output and the oscilloscope offset setting.
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Performance verification (MSO/DPO5000/B series)
Vertical scale Low limit
2 mV/div -1.5%
5 mV/div -1.5%
10 mV/div -1.5%
20 mV/div -1.5%
50 mV/div -1.5%
100 mV/div -1.5%
200 mV/div -1.5%
500 mV/div -1.5%
1 V/div -1.5%
20 mV/div -1.5%
20 mV/div -1.5%
2 mV/div -1.5%
5 mV/div -1.5%
10 mV/div -1.5%
20 mV/div -1.5%
50 mV/div -1.5%
100 mV/div -1.5%
200 mV/div -1.5%
500 mV/div -1.5%
1 V/div -1.5%
20 mV/div -1.5%
20 mV/div -1.5%
1
Vertical offset Low limit
900 mV 895.3 mV
-900 mV -904.7 mV
5.0 V 4.965 V
-5.0 V -5.035 V
Test result High limit
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
1.5%
Test result High limit
904.7 mV
-895.3 mV
5.035 V
-4.965 V
293
