Tektronix MSO70000C/DX Technical Reference page 159

Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC gain accuracy (averaged), >20 GHz models
Instrument performance test
Ch1 100 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
0 Div position setting, +3.4 V offset
0 Div position setting, +2.4 V offset
-3.4 V termination
0 Div position setting, -3.4 V offset
0 Div position setting, -2.4 V offset
-1.5 V termination
0 Div position setting, -1.5 V offset
0 Div position setting, -0.5 V offset
Ch1 120 mV Vert scale setting,
0 V termination
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
0 Div position setting, -1 V offset
+1.5 V termination
0 Div position setting, +2.5 V offset
0 Div position setting, +1.5 V offset
0 Div position setting, +0.5 V offset
+3.4 V termination
-5 Div position setting, +3.4 V offset
-5Div position setting, +2.4 V offset
-3.4 V termination
5 Div position setting, -3.4 V offset
5Div position setting, -2.4 V offset
-1.5 V termination
5 Div position setting, -1.5 V offset
5 Div position setting, -0.5 V offset
Ch1 140 mV Vert scale setting,
0 V termination
0 Div position setting, -1 V offset
0 Div position setting, 0 V offset
0 Div position setting, +1 V offset
Ch1 200 mV Vert scale setting,
0 V termination
0 Div position setting, -0.9 V offset
0 Div position setting, 0 V offset
0 Div position setting, +0.9 V offset
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Minimum Incoming
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
+ 588 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
705.6 mV __________
823.2 mV __________
823.2 mV __________
823.2 mV __________
1176 mV __________
1176 mV __________
1176 mV __________
Outgoing Maximum
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ + 612 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 734.4 mV
__________ 856.8 mV
__________ 856.8 mV
__________ 856.8 mV
__________ 1224 mV
__________ 1224 mV
__________ 1224 mV
