Performance verification (MSO/DPO5000/B series)
Delta Time Measurement Accuracy
Sample rate = 2.5 GS/s, 4 ns/Div, Source freq = 240 MHz
MSO/DPO V/Div
1 mV
5 mV
100 mV
500 mV
1 V
Sample rate = 2.5 GS/s, 40 ns/Div, Source freq = 24 MHz
1 mV
5 mV
100 mV
500 mV
1 V
Sample rate = 2.5 GS/s, 400 ns/Div, Source freq = 2.4 MHz
1 mV
5 mV
100 mV
500 mV
1 V
Sample rate = 250 MS/s, 4 μs/Div, Source freq = 240 kHz
1 mV
5 mV
100 mV
500 mV
1 V
Sample rate = 25 MS/s, 40 μs/Div, Source freq = 24 kHz
1 mV
5 mV
100 mV
500 mV
1 V
Sample rate = 2.5 MS/s, 400 μs/Div, Source freq = 2.4 kHz
1 mV
5 mV
100 mV
500 mV
1 V
MSO/DPO5054/B and MSO/DPO5034/B Channel 3
312
Source V
pp
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
8 mV
40 mV
800 mV
4 V
4 V
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Test result High limit
NA
234 ps
233 ps
233 ps
237 ps
735 ps
422 ps
357 ps
254 ps
581 ps
6.99 ns
3.54 ns
2.72 ns
2.69 ns
5.34 ns
69.9 ns
35.4 ns
27.2 ns
26.9 ns
53.4 ns
699 ns
354 ns
272 ns
269 ns
534 ns
6.99 μs
3.54 μs
2.72 μs
2.69 μs
5.34 μs
