Tektronix MSO70000C/DX Technical Reference page 26

Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
(cont.)
DPO7104C
DPO7054C
Step response settling time,
typical, >20 GHz models
DSP off
DSP on (fastest BWE setting)
14
Scale
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div
Scale
1 mV/div - 1.99 mV/div
2 mV/div - 4.99 mV/div
5 mV/div - 9.9 mV/div
10 mV/div - 1 V/div
The time by which the step response enters and stays below the indicated % error. Step transition
occurs at the 50% amplitude point of the step leading edge.
Instrument Gain setting (FS)
MSO/ 62.5 mV, 100 mV, 200 mV,
DPO73304DX,
MSO/ 500 mV, 1 V, 1.2 V, 1.4 V,
DPO72504DX,
MSO/ 2 V, 4 V
DPO72304DX
DSP on (fastest BWE setting) Instrument Gain setting (FS) Settling
Instrument Gain setting (FS)
MSO/ 62.5 mV, 100 mV, 200 mV,
DPO73304DX
MSO/ 500 mV, 1 V, 1.2 V, 1.4 V,
DPO72504DX,
MSO/ 2 V, 4 V
DPO72304DX
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Vertical system analog channels
10% - 90%
1.2 ns
580 ps
300 ps
300 ps
10% - 90%
1.2 ns
680 ps
460 ps
460 ps
Settling Error Time
<6% 150 ps – 400 ps
<5% (<5.5% 400 ps – 3 ns
MSO/ 3 ns – 1 ms
DPO73304DX)
<3%
Settling Error Time
<3.5% 150 ps – 400 ps
<2.5% 400 ps – 3 ns
<1.5% 3 ns – 1 ms
