Performance verification (MSO/DPO70000C, MSO/DPO70000DX, and DPO7000C series)
DC voltage measurement accuracy (averaged), >20 GHz models
Instrument performance test
Ch3 400 mV Vert scale setting, 0 Div position setting
0 V termination
–1 V offset
0 V offset
+1 V offset
Ch4 6.25 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
Ch4 10 mV Vert scale setting, 0 Div position setting
+3.5 V termination
+3.4 V offset
+2.4 V offset
+1.5 V termination
+2.5 V offset
+1.5 V offset
+0.5 V offset
0 V termination
0 V offset
-1 V offset
+1 V offset
-3.5 V termination
-3.4 V offset
-2.4 V offset
-1.5 V termination
-2.5 V offset
-1.5 V offset
-0.5 V offset
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Minimum Incoming
103.5 mV __________
1.1075 V __________
2.1035 V __________
3.4012 V __________
2.4032 V __________
2.49345 V __________
1.49945 V __________
501.45 mV __________
14.76 mV __________
-1.00056 V __________
999.45 mV __________
-3.4363 V __________
-2.4343 V __________
-2.52456 V __________
-1.51856 V __________
-516.56 mV __________
3.4117 V __________
2.4137 V __________
2.4988 V __________
1.5195 V __________
521.5 mV __________
25.5 mV __________
-980.5 mV __________
1.0195 V __________
-3.4117 V __________
-2.4137 V __________
-2.5312 V __________
-1.5405 V __________
-538.5 mV __________
Outgoing Maximum
__________ 296.5 mV
__________ 1.2925 V
__________ 2.2965 V
__________ 3.4363 V
__________ 2.4343 V
__________ 2.52456 V
__________ 1.51856 V
__________ 516.56 mV
__________ 22.25 mV
__________ -981.45 mV
__________ 1.01856 V
__________ -3.4012 V
__________ -2.4032 V
__________ -2.49345 V
__________ -1.49945 V
__________ -501.45 mV
__________ 3.4483 V
__________ 2.4463 V
__________ 2.5312 V
__________ 1.5405 V
__________ 538.5 mV
__________ 34.5 mV
__________ -959.5 mV
__________ 1.0405 V
__________ -3.4483 V
__________ -2.4463 V
__________ -2.4988 V
__________ -1.5195 V
__________ -521.5 mV
