Tektronix MSO70000C/DX Technical Reference page 24

Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)
(cont.)
Analog bandwidth with X10
passive probe, typical, <4 GHz
models
Analog bandwidth selections
<4 GHz models
Lower frequency limit AC coupled
<4 GHz models
Upper frequency limit 250 MHz
bandwidth limited <4 GHz models
Upper frequency limit 20 MHz
bandwidth limited <4 GHz models
Passband flatness, BWE, typical
MSO/DPO73304DX, MSO/
DPO72504DX, MSO/
DPO72304DX
MSO/DPO72004C, MSO/
DPO71604C, MSO/DPO71254C
12
Full bandwidth, operating ambient of ≤ 30 °C (86 °F), derated by 1% for each °C above 30 °C
(86 °F)
SCALE range
5 mV/div to 10 V/div
2 mV/div to 4.98 mV/div
1 mV/div to 1.99 mV/div
20 MHz, 250 MHz, and Full
10 Hz when 1 MΩ, AC coupled. The limit is reduced by a factor of 10 when 10X, passive probes
are used.
250 MHz
20 MHz
Step settings
62.5 mV , 100 mV , 200 mV
FS FS
1 VFS, 2 V , and 5 V
FS FS
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1.5 dB from 50% to 80% of nominal
bandwidth.
All other gain settings
± 1.0 dB from DC to 50% of nominal bandwidth
± 2.0 dB from 50% to 80% of nominal
bandwidth.
Use the Temperature variation table to determine the amount of performance derating above the
temperature limit.
Step settings
100 mVFS, 200 mVFS, 500 m VFS, 1 VFS, and
2.5 VFS
± 0.5 dB from DC to 50% of nominal bandwidth.
± 1.5 dB from 50% to 80% of nominal
bandwidth.
Non-step settings
± 1.0 dB from DC to 50% of nominal bandwidth
± 2.0 dB from 50% to 80% of nominal
bandwidth.
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Vertical system analog channels
Bandwidth
DC to 500 MHz
DC to 300 MHz
DC to 175 MHz
Temperature constraint
, 500 mV , At 25 °C
FS FS
Temperature constraint
At 25 °C
