Input-output port specifications (cont.)
series)
Input and output ports
DVI Video port
VGA port, DX models only
Passive eSATA Port
COM1 and COM2 serial ports
Keyboard and Mouse ports
LAN port
External audio ports
USB ports
GPIB port

Data storage specifications

Hard disk
>20 GHz models
≤20 GHz models
MSO70000C/DX, DPO70000C/DX, DPO7000C, MSO5000/B, DPO5000/B Series
Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C
>20 GHz models: A female Digital Visual Interface (DVI-D) compatible port
≤20 GHz models: A female Digital Visual Interface (DVI-I) compatible port
A female Video Graphics Array (VGA) compatible port
Instrument must be powered down to make connection
9 pin D-Sub ports, use NS16C550-compatible UARTS, transfer speeds up to 115.2 kb/s.
DX models have only COM1.
PS-2 compatible, instrument must be powered down to make connection
RJ-45 connector, supports 10 base-T, 100 base-T, and Gigabit Ethernet
External audio jacks for microphone input and line output
>20 GHz models: Four rear panel and 2 front panel USB 2.0 connectors. On DX models, two of the
rear panel connectors are USB 3.0/USB 2.0
≤20 GHz models: Four side or rear panel and 1 front panel USB 2.0 connectors
IEEE 488.2 standard interface, listener or controller
Waveforms and setups are stored on the hard disk.
2.5-inch SATA hard disk, drive capacity is ≥300 GB. DX models use a ≥300 GB solid state drive. C
models use a ≥500 GB hard disk drive.
2.5-inch SATA hard disk, drive capacity is ≥160 GB.
