Specifications (MSO70000C/DX, DPO70000C/DX, and DPO7000C series)

Power source specification

Power consumption
≥4 GHz models
<4 GHz models
Source voltage and frequency
≥4 GHz models
<4 GHz models
Value probe interface (VPI), <4 GHz
models

Mechanical specifications

Weight
<4 GHz models Benchtop
configuration
Rackmount kit
≥4 GHz non-MSO models,
Benchtop configuration
MSO70000C Series, Benchtop
configuration
MSO70000DX Series,
Benchtop configuration
Rackmount kit, ≥4 GHz
models
74
<1200 VA
550 Watts maximum
100 to 240 V , 50 Hz to 60 Hz,
RMS
115 V ± 10%, 400 Hz
CAT II
100 V to 240 V ± 10%, 47 Hz to 63 Hz
RMS
115 V ± 10%, 400 Hz
Probe interface allows installing, powering, compensating and controlling a wide range of probes
offering a variety of features.
14.0 kg (31 lbs) instrument only
21.8 kg (48 lbs) when packaged for domestic shipment
0.9 kg (2 lbs)
2.2 kg (5 lbs) kit packaged for domestic shipment
23 kg (50.6 lbs) oscilloscope only
37 kg (81.4 lbs) packaged for domestic shipment
25.0 kg (55 lbs) instrument only
39 kg (86 lbs) when packaged for domestic shipment
25.0 kg (55 lbs) instrument only
39 kg (86 lbs) when packaged for domestic shipment
2.04 kg (4.5 lbs) rackmount kit
3.4 kg (7.5 lbs) kit packaged for domestic shipment
